EasyCap Recorder
Connect STK1160, UTV007, EM2860, SMI2021 EasyCap to view and record
沈垚 / ShenYao China · com.shenyaocn.android.easycaprecorder
UpdatedMar 13, 2026
PublishedApr 7, 2021
Packagecom.shenyaocn.android.easycaprecorder
MD5f6b017afa5b674ac8a6d721cbc6d064a
SHA1 (signer)DE:5D:F6:AF:33:3B:40:F7:90:27:F5:05:51:BA:3E:77:23:94:4E:B0
Signed byCN=Yao Shen, OU=shenyaocn.com, O=shenyaocn.com, L=Zhangzhou, ST=Fujian, C=CN
Architecturesx86, x86-64, armeabi-v7a, arm64-v8a
Malware scanTRUSTED
Websitehttp://www.shenyaocn.com
Contact[email protected]
Privacy policyView
What's new
* Add support UTV007 device with VID_1f71&PID_3301, VID_1f71&PID_3306
* Can use AV1+AAC format for video recording
* The audio will continue playing after entering the background
* Optimize the full screen mode under the notch screen
* Can use AV1+AAC format for video recording
* The audio will continue playing after entering the background
* Optimize the full screen mode under the notch screen
Description
*** The Pro version can save video record and snapshot into external SD Card or USB Disk and without ads ***
Tip:
Supports following devices:
1) EasyCap including audio with UTV007 / HTV600 / HTV800 chipsets (VID_1B71&PID_3002)
2) EasyCap including audio with STK1160 + SAA7113/GM7113 + AC97 chipsets (Audio 48kHz stereo version VID_05E1&PID_0408)
3) EasyCap including audio with STK1160 + SAA7113/GM7113 (Audio 8kHz mono version VID_05E1&PID_0408)
4) EasyCap including audio with EM2860 + SAA7113/GM7113 + AC97 chipsets (VID_EB1A&PID_2861)
5) EasyCap including audio with SMI2021 + SAA7113/GM7113 + ES7240/CS5340 chipsets (VID_1C88&PID_0007, PID_003C, PID_003D, PID_003E, PID_003F, PID_1001)
Please switch the video Standard(PAL/NTSC/SECAM) if video freeze when using EasyCap.
Please use a good quality OTG cable and ensure power supply. Some devices may need to bridge HUB to enhanced USB signals to work properly, e.g. ezcap Video Grabber.
Using HEVC for video recording requires Android 5.0 or above, and the device must supports HEVC codec.
"EasyCap Recorder" can let your android device connect to EasyCap video capture card via USB-OTG. You can capture snapshot or record video WITH audio support.
"EasyCap Recorder" supports Side by Side(SBS) view and it can work with FPV goggle.
"EasyCap Recorder" can seamless switching between foreground and background. The recording will not interrupted during switching!
This is userspace driver so it used for the app only. Android does not allow to install kernel driver so it unable to use for third-party apps.
Tip:
Supports following devices:
1) EasyCap including audio with UTV007 / HTV600 / HTV800 chipsets (VID_1B71&PID_3002)
2) EasyCap including audio with STK1160 + SAA7113/GM7113 + AC97 chipsets (Audio 48kHz stereo version VID_05E1&PID_0408)
3) EasyCap including audio with STK1160 + SAA7113/GM7113 (Audio 8kHz mono version VID_05E1&PID_0408)
4) EasyCap including audio with EM2860 + SAA7113/GM7113 + AC97 chipsets (VID_EB1A&PID_2861)
5) EasyCap including audio with SMI2021 + SAA7113/GM7113 + ES7240/CS5340 chipsets (VID_1C88&PID_0007, PID_003C, PID_003D, PID_003E, PID_003F, PID_1001)
Please switch the video Standard(PAL/NTSC/SECAM) if video freeze when using EasyCap.
Please use a good quality OTG cable and ensure power supply. Some devices may need to bridge HUB to enhanced USB signals to work properly, e.g. ezcap Video Grabber.
Using HEVC for video recording requires Android 5.0 or above, and the device must supports HEVC codec.
"EasyCap Recorder" can let your android device connect to EasyCap video capture card via USB-OTG. You can capture snapshot or record video WITH audio support.
"EasyCap Recorder" supports Side by Side(SBS) view and it can work with FPV goggle.
"EasyCap Recorder" can seamless switching between foreground and background. The recording will not interrupted during switching!
This is userspace driver so it used for the app only. Android does not allow to install kernel driver so it unable to use for third-party apps.
Required features
- Usb Host android.hardware.usb.host
Permissions (13)
EasyCap Recorder requests the following Android permissions:
- Access Adservices Ad Id android.permission.ACCESS_ADSERVICES_AD_ID
- Access Adservices Attribution android.permission.ACCESS_ADSERVICES_ATTRIBUTION
- Access Adservices Topics android.permission.ACCESS_ADSERVICES_TOPICS
- Access Network State android.permission.ACCESS_NETWORK_STATE
- Foreground Service android.permission.FOREGROUND_SERVICE
- Foreground Service Media Playback android.permission.FOREGROUND_SERVICE_MEDIA_PLAYBACK
- Internet android.permission.INTERNET
- Post Notifications android.permission.POST_NOTIFICATIONS
- System Alert Window android.permission.SYSTEM_ALERT_WINDOW
- Usb Permission android.permission.USB_PERMISSION
- Wake Lock android.permission.WAKE_LOCK
- Gms Permission Ad Id com.google.android.gms.permission.AD_ID
- Com Shenyaocn Android Easycaprecorder Dynamic Receiver Not Exported Permission com.shenyaocn.android.easycaprecorder.DYNAMIC_RECEIVER_NOT_EXPORTED_PERMISSION
